Welded Wire Mesh Roll

Inquire Now

Product details

Introduction

Welded Wire Mesh Roll are the suitable products for constructing animal cages, enclosure works, fabricating of wire containers and baskets, grills, partitions, machine protection fences, gratings and other construction applications.

The finished welded mesh offer flat and uniform surface, firm structure, good integrity. The welded wire mesh are the most excellent anti-corrosion resistance among all the steel wire mesh products, it is also the most versatile wire mesh due to its wide application in different fields. The welded wire mesh can be galvanized, PVC coated, or stainless steel welded wire mesh

Technology

Surface finishing	Color	Wire gauge explanation	Hole size explanation
Electro galvanized	silver	BWG 12 (2.5MM) BWG 14 (2MM) BWG 15 (1.8MM) BWG 16(1.6MM) BWG18(1.2MM BWG19(1MM) Etc....	25.4mm is 1” holes are perfect for small animal’s enclosures, hutches, cages, chicken coops and rabbit runs. 50.8mm is 2” holes are perfect for creating fencing for larger animals such as dogs.
Hot dipped galvanized	silver
PVC coated	Green, white,blue, yellow,black,brown.... many kinds of color
Stainless steel	silver

Specifications

Opening		Wire Diameter BWG
In inch	In metric unit(mm)
1/4" x 1/4"	6.4mm x 6.4mm	22,23,24
3/8" x 3/8"	10.6mm x 10.6mm	19,20,21,22
1/2" x 1/2"	12.7mm x 12.7mm	16,17,18,19,20,21,22,23
5/8" x 5/8"	16mm x 16mm	18,19,20,21,
3/4" x 3/4"	19.1mm x 19.1mm	16,17,18,19,20,21
1" x 1/2"	25.4mm x 12.7mm	16,17,18,19,20,21
1-1/2" x 1-1/2"	38mm x 38mm	14,15,16,17,18,19
1" x 2"	25.4mm x 50.8mm	14,15,16
2" x 2"	50.8mm x 50.8mm	12,13,14,15
2” x 4"	50.8mm x 101.6mm	12,13,14,15
4” x 4"	101.6mm x 101.6mm	12,13,14,15
4” x 6"	101.6mm x 152.4mm	12,13,14,15
6” x 6"	152.4mm x 152.4mm	12,13,14,15
6” x 8"	152.4mm x 203.2mm	12,13,14
Roll Width	From 0.4m to 2m
Roll length	From 5m to 50m
Material	Galvanized wire, stainless steel wire, PVC coated wire
Packing	With a piece of craft paper inside and then a plastic film, Also available upon your requirements

Features

1. Provided as a roll for easier transport – simply unroll and cut as required

2. Galvanized with a zinc coating to give it a longer life against the elements

3. Resistant to corrosion and rust

4. Welded at each mesh join to ensure it is strong, long-lasting and secure

5. Available with a galvanized steel finish or PVC-coated galvanized steel finish or stainless steel wire welded

Application

Suitable product for constructing animal cages, enclosure works, fabricating of wire containers and baskets, grills, partitions,machine protection fences, gratings and other construction applications
